One Point Type Gas Detector

One Point Type Gas Detector

Product Details:

  • Material Plastic
  • Product Type One Point Type Gas Detector
  • Application Industrial
  • Color Grey
  • Supply Ability : 100 , , Piece Per Week
  • Click to view more
X

Price And Quantity

  • 1 , , Piece
  • INR

Product Specifications

  • One Point Type Gas Detector
  • Plastic
  • Grey
  • Industrial

Trade Information

  • 100 , , Piece Per Week
  • 1 Week

Product Description

One Point Type

  • Simpler, smarter and reliable gas detector with digital display
  • Simple and cost effective installation
  • Rugged, compact and lightweight design
  • Environmentally friendly product.

Features

LED Display

Large and easy-to-see display shows the gas concentration and alarm indication

Easy maintenance

With a magnetic stick, zero and span adjustments can be done with out any difficulty on site.

Easy sensor replacement

The simple plug-in sensor module makes it easier.

Rugged, Compact and lightweight

Protection rating, IP65(Standard)

Size W 158xH116xD68mm, weight 1.2 kg

Explosion-Proof

KD-12A/B/C are designed as ExdIII CT5 for Hydrogen and Acetylene.

Technical Specifications

Mode

KD-12A

KD-12B

KD-12C

KD12D

KD-12O

Corresponding Sensor type

Hot wire semiconductor

Catlytic combustion

Thermal conductivity

Electrochemical cell

Galvanic cell

Target gas

Combustible/toxic gas

Hydrogen, Helium, Carbon dioxide

Carbon monoxide

Hydrogen sulfide

Oxygen

Sampling Method

Diffusion type

Detection range

As per specifications


0-100ppm, 0-150ppm or 0-250ppm

0-30ppm or 0-50ppm

0-25.0 vol%

Alarm Accuracy

Combustible gas: +25% of alarm set value(under identical conditions)

+30% of Alarm set value(under identical conditions)

+1.0 vol% of Alarm set value(under identical conditions)

Warning Display

Gas Alarm: Red LED lamps flashes
Trouble Alarm: Yellow LED lamp flashes(sensor trouble, power voltage mulfunction, etc.

Gas concentration Display

4-digit digital LED display

Cable connection

Screw-less/terminal block

Cable connection

Screw-less/terminal block

Degree of protection

IP65

Power supply

24V DC(18 to 30V DC)

Weight

Approx. 1.2 kg

Approx. 1.3 kg
